1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic

1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic

    • 1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic
    • 1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic
  • 1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic

    Product Details:

    Place of Origin: CHINA
    Brand Name: RTCRAFT or OEM
    Certification: ISO,MPA,TUV
    Model Number: 0.1-20mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: pvc bag,blister card,plastic tube,plastic box
    Delivery Time: about 20 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 1000000pcs/month
    Contact Now
    Detailed Product Description
    Product Name:: HSS Drill Bits Material:: High Speed Steel
    Point:: 118 Degree Processing:: Polished
    Type:: 1-20mm Standard:: Din Or Ansi

    DIN338 Straight Shank HSS Drill Bits for Metal with Bright Finished Polished



    Quick Details of DIN338 Drill Bits:

    1. Material:HSS 4241,4341,6542;

    2. Process:Polished

    3. Surface:Bright Finished

    4. Point:118°

    5. Shank:Straight Shank

    6. Drilling holes on aluminium,plastic,wood,copper,iron



    HSS Twist Drill Bits Features:

    1. Material and Hardness of High Speed Steel:

    DESCRIPTION OF HSS C W Mo Cr V Co Si Mn P S
      % % % % % % % % % %
    W2MoCr4V(F4341) 0.95-1.05 1.7-2.4 0.8-1.2 3.8-4.4 0.8-1.2   1.0-1.4 0.2-0.4 <=0.03 <=0.03
    W4Mo3Cr4V(4341) 0.88-0.98 3.5-4.5 2.5-3.5 3.8-4.4 1.2-1.8   0.5-1.2 0.2-0.4 <=0.03 <=0.03
    W9Mo3Cr4V(9341) 0.77-0.87 8.5-9.5 2.7-3.3 3.8-4.4 1.3-1.7 - 0.2-0.4 0.2-0.4 <=0.03 <=0.03
    W6Mo5Cr4V2(M2) 0.8-0.9 5.5-6.75 4.5-5.5 3.8-4.4 1.75-2.2 - 0.2-0.4 0.2-0.4 <=0.03 <=0.03
    W6Mo5Cr4V2Co5(M35) 0.9-0.95 5.5-6.5 4.5-5.5 3.8-4.4 1.75-2.2 4.5-5.5 0.2-0.4 0.2-0.4 <=0.03 <=0.03
    W2Mo9Cr4V2Co8(M42) 1.05-1.15 1.15-1.85 9.0-10.0 3.5-4.25 0.95-1.25 7.75-8.75 0.15-0.65 0.15-0.4 <=0.02 <=0.025

    2. Size of HSS Drill Bits for Steel:



    1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic

    D(mm) L2(mm) L1(mm) D(mm) L2 (mm) L1(mm) D(mm) L2 (mm) L1(mm) D(mm) L2 (mm) L1(mm)
    0.2 2.5 19 1.95 24 49 6 57 93 11.2 94 142
    0.22 2.5 19 2 24 49 6.1 63 101 11.3 94 142
    0.25 3 19 2.05 24 49 6.2 63 101 11.4 94 142
    0.28 3 19 2.1 24 49 6.3 63 101 11.5 94 142
    0.3 3 19 2.15 27 53 6.4 63 101 11.6 94 142
    0.32 4 19 2.2 27 53 6.5 63 101 11.7 94 142
    0.35 4 19 2.25 27 53 6.6 63 101 11.8 94 142
    0.38 4 19 2.3 27 53 6.7 63 101 11.9 101 151
    0.4 5 20 2.35 27 53 6.8 69 109 12 101 151
    0.42 5 20 2.4 30 57 6.9 69 109 12.1 101 151
    0.45 5 20 2.45 30 57 7 69 109 12.2 101 151
    0.48 5 20 2.5 30 57 7.1 69 109 12.3 101 151
    0.5 6 22 2.55 30 57 7.2 69 109 12.4 101 151
    0.52 6 22 2.6 30 57 7.3 69 109 12.5 101 151
    0.55 7 24 2.65 30 57 7.4 69 109 12.6 101 151
    0.58 7 24 2.7 33 61 7.5 69 109 12.7 101 151
    0.6 7 24 2.75 33 61 7.6 75 117 12.85 101 151
    0.62 8 26 2.8 33 61 7.7 75 117 12.9 101 151
    0.65 8 26 2.85 33 61 7.8 75 117 13 101 151
    0.68 9 28 2.9 33 61 7.9 75 117 13.1 101 151
    0.7 9 28 2.95 33 61 8 75 117 13.2 101 151
    0.72 9 28 3 33 61 8.1 75 117 13.3 108 160
    0.75 9 28 3.1 36 65 8.2 75 117 13.4 108 160
    0.78 10 30 3.2 36 65 8.3 75 117 13.5 108 160
    0.8 10 30 3.3 36 65 8.4 75 117 13.6 108 160
    0.82 10 30 3.4 39 70 8.5 75 117 13.7 108 160
    0.85 10 30 3.5 39 70 8.6 81 125 13.8 108 160
    0.88 11 32 3.6 39 70 8.7 81 125 13.9 108 160
    0.9 11 32 3.7 39 70 880 81 125 14 108 160
    0.92 11 32 3.8 43 75 8.9 81 125 14.25 114 169
    0.95 11 32 3.9 43 75 9 81 125 14.5 114 169
    0.98 12 34 4 43 75 9.1 81 125 14.75 114 169
    1 12 34 4.1 43 75 9.2 81 125 15 114 169
    1.05 12 34 4.2 43 75 9.3 81 125 15.25 120 178
    1.1 14 36 4.3 47 80 9.4 81 125 15.5 120 178
    1.15 14 36 4.4 47 80 9.5 81 125 15.75 120 178
    1.2 16 38 4.5 47 80 9.6 87 133 16 120 178
    1.25 16 38 4.6 47 80 9.7 87 133 16.25 125 184
    1.3 16 38 4.7 47 80 9.8 87 133 16.5 125 184
    1.35 18 40 4.8 52 86 9.9 87 133 16.75 125 184
    1.4 18 40 4.9 52 86 10 87 133 17 125 184
    1.45 18 40 5 52 86 10.2 87 133 17.25 130 191
    1.5 18 40 5.1 52 86 10.3 87 133 17.5 130 191
    1.55 20 43 5.2 52 86 10.4 87 133 17.75 130 191
    1.6 20 43 5.3 52 86 10.5 87 133 18 130 191
    1.65 20 43 5.4 57 93 10.6 87 133 18.5 135 198
    1.7 20 43 5.5 57 93 10.7 94 142 18.75 135 198
    1.75 22 46 5.6 57 93 10.8 94 142 19 135 198
    1.8 22 46 5.7 57 93 10.9 94 142 19.25 140 205
    1.85 22 46 5.8 57 93 11 94 142 19.5 140 205
    1.9 22 46 5.9 57 93 11.1 94 142 19.75 140 205
                      20 140 205



    Package:

    1. Normal Package:5/10 pcs in a plastic bag,then inner box and out carton.

    2. Other package:Blister card,Plastic tube,PVC pouch,according to your requirments.

    3. HSS Drill bits set are available.

    1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic

    Delivery:



    1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic

    Sample Policy:

    We can provide samples for free to test quality!



    1-13mm DIN338 Straight Shank HSS Drill Bits Bright Finished Polished For Aluminium / Plastic



    Q1: How to deliver the goods?

    Deliver By sea,By air,By express.

    Q2: How long is the leading time?

    According to your order,we usually finish producing about 20-30days.

    Q3: Which payment we can accept?

    We accept Payment:Bank transfer,Wester Union,Paypal.
